| Specifications
|
|
| Model DS-7304HQHI-K4 DS-7308HQHI-K4 DS-7316HQHI-K4 | |
| Recording | |
| Video compression H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 | |
| Encoding resolution | |
| When 1080p Lite mode is not enabled: | |
| 4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF; | |
|
|
| 4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF | |
| Frame rate | |
| Main stream: | |
| When 1080p Lite mode is not enabled: | |
| For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/ | |
| CIF@25fps (P)/30fps (N) | |
| For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps | |
| For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P) | |
| /30fps (N) | |
| For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) | |
| When 1080p Lite mode enabled: | |
| 4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/ 30fps | |
| (N) | |
| Sub-stream: | |
| WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) | |
| Video bit rate 32 Kbps to 6 Mbps | |
| Dual stream Support | |
| Stream type Video, Video & Audio | |
| Audio compression G.711u | |
| Audio bit rate 64 Kbps | |
| Video and Audio | |
| IP video input | |
| 2-ch (up to 6-ch) 4-ch (up to 12-ch) 8-ch (up to 24-ch) | |
| Up to 6 MP resolution | |
| Support H.265+/H.265/H.264+/H.264 IP cameras | |
| Analog video input | |
| 4-ch 8-ch 16-ch | |
| BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection | |
| HDTVI input | |
| 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25 | |
| *: The 3 MP signal input is only available for channel 1 of DS-7304HQHI-K4, | |
| channel 1/2 of DS-7308HQHI-K4, and channel 1/2/3/4 of DS-7316HQHI-K4. | |
| AHD input 4 MP, 1080p25, 1080p30, 720p25, 720p30 | |
| HDCVI input 1080p25, 1080p30, 720p25, 720p30 | |
| CVBS input PAL/NTSC | |
| CVBS output 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 | |
| VGA/HDMI output | |
| VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × | |
| 768/60Hz | |
| HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, | |
| 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz | |
| Audio input 4-ch, RCA (2.0 Vp-p, 1 KΩ) | |
| Audio output 2-ch, RCA (Linear, 1 KΩ) | |
| Two-way audio 1-ch, RCA (2.0 Vp-p, 1 KΩ) (independent) | |
| Synchronous playback 4-ch 8-ch 16-ch | |
| Network | |
| Remote connections 128 | |
| Network protocols | |
| TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, | |
| HTTPS, ONVIF, SNMP | |
| Network interface 1, RJ45 10M/100M/1000M self-adaptive Ethernet interface | |
| Auxiliary interface | |
| SATA 4 SATA interfaces | |
| eSATA Support | |
| Capacity Up to 10 TB capacity for each disk | |
| Serial interface RS-232, RS-485 (full-duplex), Keyboard | |
| USB interface | |
| Front panel: 2 × USB 2.0 | |
| Rear panel: 1 × USB 3.0 | |
| Alarm in/out 16/4 | |
| General | |
| Power supply 100 to 240 VAC | |
| Consumption | |
| (without HDD) | |
| ≤ 30 W ≤ 40 W ≤ 55 W | |
| Working temperature -10 °C to +55 °C (+14 °F to +131 °F) | |
| Working humidity 10% to 90% | |
| Dimensions (W × D × H) 445 × 390 × 70 mm (17.5 × 15.4 × 2.8 inch) | |
| Weights (without HDD) ≤ 5 kg (11.0 lb) |
Previous product
Back to products
DS-7304HQHI-K4 (Turbo HD 4.0)
රු129,749.00
Next product
DS-7316HQHI-K4 (Turbo HD 4.0)
රු217,792.00
DS-7308HQHI-K4 (Turbo HD 4.0)
රු171,454.00
| DS-7308HQHI-K4 (Turbo HD 4.0)
8-ch 1080p 1.5U H.265 DVR |
| 8 channels and 4 HDDs 1.5U DVR |
| Efficient H.265 pro+ compression technology |
| Encoding ability up to 1080p @ 15 fps |
| 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP) |
| Up to 12 network cameras can be connected |
| Supports POS triggered recording and POS information overlay |
