SPECIFICATIONS
Image Sensor 1/2.7″CMOS
Min. Illumination Color:0.002Lux@(F1.6,AGC ON),B/W:0Lux with IR
Shutter Time 1s~1/100000s
Day&Night IR-cut filter with auto switch (ICR)
Smart IR Yes
WDR DWDR
S/N >39dB
Angle Adjustment 0~330°(P); 0~75°(T); 0~350°(R)
Lens
Lens Type Fixed focal lens
Focal Length 2.8mm
Lens Mount M12
Aperture Range F1.6
Aperture Type Fixed
Field of View 109°(H); 59°(V); 125.4°(D)
DORI Distance Detect:56m
Observe:22.2m
Recognize:11.2m
Identify:5.6m
Illuminator
IR LEDs 8
IR Distance Up to 30m
Wavelength 850nm
Compression Standard
Video Compression S+265/H.265/H.264B/H.264M/H.264H
Video Bit Rate 32k~6Mbps
Audio Compression G.711A/G.711U/ADPCM_D
Audio Sampling Rate 8kHz/32kHz/48kHz
Max. Resolution 4MP,2688×1520@25fps
Main Stream PAL:25fps(2688×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720)
NTSC:24fps(2688×1520, 2560×1440), 30fps(2304×1296, 1920×1080, 1280×720)
Sub Stream PAL:25fps(704×576, 704×288, 640×360, 352×288)
NTSC:30fps(704×480, 704×240, 640×360, 352×240)
BLC Yes
HLC Yes
AGC Yes
3D DNR Yes
White Balance Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock
White Balance
2024.06.24
OSD Overlay of additional characters in 1 regions, 1 line, with a maximum of 48 characters or 16 Chinese
characters per region; 16*16/32*32/48*48/64*64; Lattice
Privacy Mask 4 black static areas
Defog Yes
Feature
General Alarm Motion Detection; Mask Alarm
Exceptions Alarm Disk Full; Disk R/W Error; IP Address Conflict; Network Disconnection
Linkage Method Trigger Recording; Trigger Capture; Notify Surveillance Center
Video Analytics Tripwire; Perimeter
Rules of Behavior Analyse In 1
Scene
2
Network
ANR Yes
Protocols RTSP; HTTP; HTTPS; TCP; UDP; UPnP; ICMP; DHCP; DNS; DDNS; Easy DDNS; NTP; TLS v1.2; QoS; IPv4;
SSH; Unicast; FTP
System Compatibility P2P(Mutually exclusive with Profile G); ONVIF(Profile S/T/G) ; SDK; CGI; Milestone
Remote Connection ≤2
Client Easy7 VMS
Moblie Client EasyLive Plus
Web IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+
Interface
Communication Interface 1×RJ-45 (10/100 Base-T)
Built-in Mic 1×Built-in Mic
Reset Button Yes(Built-in)
On-board Storage Support microSD/microSDHC/microSDXC card,up to 512GB
General
Web Client Language 19 languages
Simple Chinese/Traditional Chinese/English/Spanish/Korean/Italian/Turkish/Russian/Thai/French/
Polish/Dutch/Hebrew/Arabic/Vietnamese/German/Ukrainian/Portuguese/Albanian
Operating Temperature -30°C~60°C(-22°F~140°F)
Operating Humidity ≤95%RH
Storage Temperature -30°C~60°C(-22°F~140°F)
Storage Humidity 10%~95%RH(non-condensing)
Power Supply PoE:IEEE 802.3af,Max. 6W
Protection Surge4000V; ESD6000V; IP66; IK10
Boundary Dimensions 120(L)120(W)90(H)mm
Package Dimensions 140(L)140(W)120(H)mm
GrossWeight 0.61kg
